Steelo Fabrica is a perfect solution for EN-9 Round Bar and Rod. Our company not only manufacture but also export these round bar worldwide. We design these round bars using international standards as per the request of the customer we produce these round bars. If an application needs a different size, dimension, and length of round bars, we can provide it to the customer. At a competitive rate, we offer our round bars and other products. These round bars are supplied by us is used in various industries.
Table of Content
Description of EN9 alloy:
EN9 carbon steel as medium carbon steel is generally provided in the rolled state. It can be flame or induction hardened to produce high surface hardness with excellent wear resistance for carbon steel grade. The EN9 bar is available in full length or can be cut to suit your needs. Flame-cut steel plates with EN9 carbon steel round bar can be delivered cut to required and standardized dimensions.
EN-9 Round Bar and Rod:
EN-9 Rod is supplied in an as rolled condition. These round bars are hardened by the induction process. This round bar is immune to corrosion and has higher tensile strength.
In comparison to some stainless steel grades, the EN-9 material rate is lower due to the low alloying cost. Our company offers these round bars has some features like robust construction, Easy to use and available in all dimensions. These round bars and rods show physical properties like density, coefficient of thermal expansion, and modulus of elasticity.
What are the applications of EN-9 Round Bar?
EN9 is commonly used for many general engineering applications. Typical applications include shafts, axes, knives, bushings, crankshafts, screws, scythes, wood drills, and hammers. Round bars are made from this alloy are used in various industries like Power Plant, Fabrication industry.
ASTM A-510
ASME SA-510
AISI 1055
WNR. CK55
Specification : ASTM A510, ASME SA510
size: 4 to 100mm
Hollow Bar : 32mm OD x 16mm ID to 250mm OD x 200mm ID)
Hex Bar : 2-100mm A/F
Angle bar size : 3mm*20mm*20mm~12mm*100mm*100mm
Rectangles Size : 33 x 30mm to 295 x 1066mm
Flat bar size : Thickness: 2 -100mm, Width: 10 to 500mm
Channel Bar : 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness
Section : 3.0 to 12.0mm thickness
Round bar size : Diameter: 3-~800mm
Round Bar Billet Size : 1/2″ to 495mm Diameter
Round Bar Surface : Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline
EN-9 Tolerance : H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
EN-9 Technique : EN-9 Round Bar Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod
Round Bar Condition : Hardened & tempered, annealed
Finish : Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
Processing : Bar cutting to 650mm
| Standard | UNS | WERKSTOFF NR. | BS | IS | JIS | EN | SAE/AISI |
| CS EN-9 | – | CK55 | 070M55 | C55 | – | EN9 | 1055 |
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
| EN9 Rounds Bright Drawn/Turned | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size (inches) | 1/2 | 9/16 | 5/8 | 3/4 | 7/8 | 1 | 1 1/8 | 1 1/4 | 1 3/8 | 1 1/2 | 1 3/4 | 1 7/8 | 2 | 2 1/8 |
| 2 | 3 | 3 | – | – | – | – | – | – | – | – | – | – | – | |
| EN9 Rounds Hot Rolled | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size (mm) | 32 | 40 | 45 | 50 | 55 | 65 | 70 | 75 | 80 | 85 | 90 | 95 | 100 | 110 |
| 120 | 125 | 130 | 140 | 150 | 160 | 180 | 190 | 200 | 220 | 280 | – | – | – | |
| EN9 Steel Plate offer cutting service on all material | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dimensions mm | Dimensions mm | Dimensions mm | Dimensions mm | |||||||||||
| 2500 x 1250 x 6 | – | 2500 x 1250 x 15 | – | 2500 x 1250 x 40 | – | 2500 x 1250 x 80 | ||||||||
| 3000 x 1500 x 6 | – | 3000 x 1500 x 15 | – | 3000 x 1500 x 40 | – | 3000 x 1500 x 80 | ||||||||
| 4000 x 2000 x 6 | – | 4000 x 2000 x 15 | – | 4000 x 2000 x 40 | – | 4000 x 2000 x 80 | ||||||||
| – | – | – | – | – | – | – | ||||||||
| 2500 x 1250 x 8 | – | 2500 x 1250 x 20 | – | 2500 x 1250 x 50 | – | 2500 x 1250 x 90 | ||||||||
| 3000 x 1500 x 8 | – | 3000 x 1500 x 20 | – | 3000 x 1500 x 50 | – | 3000 x 1500 x 90 | ||||||||
| 4000 x 2000 x 8 | – | 4000 x 2000 x 20 | – | 4000 x 2000 x 50 | – | 4000 x 2000 x 90 | ||||||||
| – | – | – | – | – | – | – | ||||||||
| 2500 x 1250 x 10 | – | 2500 x 1250 x 25 | – | 2500 x 1250 x 60 | – | 2500 x 1250 x 100 | ||||||||
| 3000 x 1500 x 10 | – | 3000 x 1500 x 25 | – | 3000 x 1500 x 60 | – | 3000 x 1500 x 100 | ||||||||
| 4000 x 2000 x 10 | – | 4000 x 2000 x 25 | – | 4000 x 2000 x 60 | – | 4000 x 2000 x 100 | ||||||||
| – | – | – | – | – | – | – | ||||||||
| 2500 x 1250 x 12 | – | 2500 x 1250 x 30 | – | 2500 x 1250 x 70 | – | – | ||||||||
| 3000 x 1500 x 12 | – | 3000 x 1500 x 30 | – | 3000 x 1500 x 70 | – | – | ||||||||
| 4000 x 2000 x 12 | – | 4000 x 2000 x 30 | – | 4000 x 2000 x 70 | – | – | ||||||||
HOW TO GET BEST PRICE OF EN 9 Round Bars ?
If looking for EN 9 Round Rods in exact length so first check Carbon Steel EN 9 price per KG in India and calculate with wight chart before negotiating with your supplier.
| Specification BS 970: 1955 | Chemical Composition | BS 970:1991/1983 Nearest Equivalent | |||||||
| C | Si | Mn | Ni | Cr | Mo | S | P | ||
| % | % | % | % | % | % | % | % | ||
| EN9 | 0.50/0.60 | 0.05/0.35 | 0.50/0.80 | – | – | – | 0.06Max | 0.06Max | 070M55 |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac IZODFT.L.b | KCV Joules | Hardness HB | Limited Ruling Section mm |
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
We offer a broad range of ASTM A510 EN 9 Round Bars through a worldwide network of stock-keeping branches. These EN 9 Carbon Steel Round Bar is use in various industries like :
Muscat, Faridabad, Gurgaon, Tehran, Visakhapatnam, Howrah, Ankara, Atyrau, Kolkata, New Delhi, Ludhiana, Caracas, Karachi, Riyadh, Haryana, Ahmedabad, Dallas, Baroda, Houston, Rajkot, Bengaluru, Abu Dhabi, Al Jubail, Busan, Vadodara, New York, Aberdeen, Melbourne, Mumbai, Ulsan, Kuwait City, Calgary, Manama, Chiyoda, Rio de Janeiro, Jeddah, Granada, Port-of-Spain, Ranchi, Sharjah, Doha, Chennai, Milan, Nashik, Brisbane, Ho Chi Minh City, Edmonton, Bangkok, Navi Mumbai, Cairo, Courbevoie, Thiruvananthapuram, Surat, Coimbatore, Hyderabad, Bogota, Chandigarh, Ernakulam, Madrid, Pimpri-Chinchwad, Indore, Bhopal, Jaipur, Thane, Nagpur, Algiers, Seoul, Noida, Toronto, Jakarta, Secunderabad, Dammam, Jamshedpur, Kanpur, Pune, Ahvaz, Istanbul, Lagos.
Steelo Fabrica is an ISO 9001:2015 Certified Manufacturer, Wholesaler, Supplier, Importer, Exporter, and Trader of a wide range of Bars and wires in a variety of materials like Stainless Steel, Duplex Steel, Inconel, Nickel, Hastelloy Titanium and Tantalum, Carbon Steel and more.
