Steelo Fabrica is a significant organization that delivers, exports, and manufactures the valid criteria of Inconel X750 Wires.
What is Inconel X750 Alloy?
Inconel Alloy X-750 is a precipitation-hardenable nickel-chromium combination utilized for its consumption and oxidation opposition and high strength at temperatures to 1300°F. Albeit a significant part of the impact of precipitation solidifying is lost with expanding temperature over 1300°F, heat-treated material has valuable strength up to 1800°F. Alloy X-750 additionally has excellent features related to cryogenic temperatures.
Table of Content
What is Inconel X750 Wire?
The Inconel X-750 Welding Wire is a Nickel-Chromium-Iron combination that highlights exceptional protection from weakening, oxidation, and fantastic execution at outrageous temperatures. The nickel content held inside the actual wire permits it to be, for the most part, invulnerable to chloride-particle stress-erosion cracking.
Depending on the application and the properties, different heat treatments are utilized. For above 1100°F, primarily where pressure is supported for significant time frames, ideal properties are accomplished by arranging heat treatments.
For low temperatures like below 1100°F, the composite might be reinforced by precipitation treating after hot or cold working or by precipitation treating after treating. A heater cooling treatment is additionally used to foster ideal properties for specific applications. The different heat treatments and the properties created are represented under the part on Mechanical Properties.
Specialties of Inconel X750:
A high-temperature nickel combination displays high protection from oxidation and synthetic consumption. This combination offers high-pressure break strength and low downer rates under high burdens at temperatures up to 1500°F (816°C). Alloy X750 is the most widely recognized Inconel and is a magnificent development material for custom springs and wire structures for high-temperature applications.
Application of Inconel X750 Wire
Inconel Alloy X-750 is utilized broadly in rocket-motor push chambers. Airframe applications incorporate push reversers and hot-air ducting frameworks. Enormous strain vessels are shaped from Inconel Alloy X-750.
Different applications are heat-treating installations, shaping devices, expulsion kicks the bucket, and test machine holds. Inconel x750 Filler wires are utilized to manufacture custom springs and wire structures for use in highly high-temperature conditions. Ordinary uses incorporate warmth treating installations, stream motor parts, framing instruments, thermal energy station applications, and expulsion kicks the bucket. The material is cold-drawn, and precipitation solidified after creation.
Specification : ASTM B637 / ASME SB637
Dimensions : ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Wire Length : Cut Lengths: 0.125″ to 72″
No Limit on Spooled Lengths
Wire Diameter : 0.0004″ to 0.040″
10 microns to 1.0 mm
Other Sizes on Request
Wire Density : 8.89 g/cm3
Surface : Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel X-750 | 2.4669 | N07750 |
| Wires Diameter(mm) | Aperture (mm) | Mesh | Length(M) | Weight (Kg) |
|---|---|---|---|---|
| 4.00 | 40 | 0.58 | 30 | 142 |
| 4.00 | 30 | 0.75 | 30 | 182 |
| 4.00 | 25 | 0.87 | 30 | 213 |
| 3.2 | 25 | 0.87 | 30 | 141 |
| 3.2 | 20 | 1.1 | 30 | 169 |
| 2.6 | 20 | 1.12 | 30 | 116 |
| 2.6 | 18 | 1.23 | 30 | 127 |
| 2.6 | 15 | 1.44 | 30 | 173 |
| 2.0 | 15 | 1.49 | 30 | 92 |
| 2.0 | 12 | 1.8 | 30 | 110 |
| 2.0 | 10 | 2.12 | 30 | 127 |
| 2.0 | 8 | 2.54 | 30 | 155 |
| 1.8 | 7 | 3 | 30 | 149 |
| 1.8 | 6 | 3.25 | 30 | 161 |
| 1.6 | 7 | 3 | 30 | 117 |
| 1.6 | 6 | 3.35 | 30 | 131 |
| 1.6 | 5 | 3.85 | 30 | 150 |
| 1.6 | 4 | 4.5 | 30 | 176 |
| 1.6 | 3 | 5.5 | 30 | 215 |
| 1.4 | 6 | 3.5 | 30 | 105 |
| 1.4 | 5 | 4 | 30 | 120 |
| 1.4 | 4 | 4.7 | 30 | 140 |
| 1.2 | 8 | 2.7 | 30 | 59 |
| 1.2 | 7 | 3.1 | 30 | 68 |
| 1.2 | 6 | 3.5 | 30 | 77 |
| 1.2 | 5 | 4 | 30 | 88 |
| 1.2 | 4 | 4.9 | 30 | 99 |
| 1.2 | 3 | 6 | 30 | 132 |
| 1.0 | 6 | 3.6 | 30 | 55 |
| 1.0 | 5 | 4.25 | 30 | 65 |
| 1.0 | 4 | 5 | 30 | 76 |
| 1.0 | 3.2 | 6 | 30 | 92 |
| 1.0 | 3 | 6.35 | 30 | 97 |
| 1.0 | 2.18 | 8 | 30 | 122 |
| 0.8 | 2.83 | 7 | 30 | 68 |
| 0.8 | 2.38 | 8 | 30 | 78 |
| 0.8 | 2.2 | 8.5 | 30 | 83 |
| 0.8 | 2 | 9 | 30 | 88 |
| 0.8 | 1.75 | 10 | 30 | 98 |
| 0.8 | 1.5 | 11 | 30 | 108 |
| 0.8 | 1.3 | 12 | 30 | 118 |
| 0.7 | 1.4 | 12 | 30 | 90 |
| 0.7 | 1.84 | 10 | 30 | 75 |
| 0.6 | 1.21 | 14 | 30 | 77 |
| 0.6 | 1.52 | 12 | 30 | 66 |
| 0.6 | 1.94 | 10 | 30 | 55 |
| 0.5 | 1.3 | 14 | 30 | 54 |
| 0.5 | 1.09 | 16 | 30 | 61 |
| 0.5 | 0.9 | 18 | 30 | 69 |
| 0.5 | 0.77 | 20 | 30 | 76 |
| Gauge A.S.W |
Diameter Inches |
Roll Thread |
Weight: Pounds/Foot Iron Steel |
Length Feet/Pound Iron Steel |
|---|---|---|---|---|
| 0.630 0.625 0.562 0.500 |
1.0588 1.0420 0.8425 0.6669 |
0.94 0.96 1.19 1.50 |
||
| 7/0 | 0.490 0.464 |
1/2-20 |
0.6405 0.5743 |
1.56 1.74 |
| 6/0 | 0.462 0.445 0.441 0.437 |
1/2-13 1/2-12 |
0.5694 0.5283 0.5188 0.5094 |
1.76 1.86 1.93 1.96 |
| 5/0 | 0.430 0.401 |
7/16-20 |
0.4932 0.4290 |
2.03 2.33 |
| 4/0 | 0.394 0.386 0.375 |
7/16-14 |
0.4141 0.3975 0.3751 |
2.41 2.52 2.67 |
| 3/0 | 0.362 0.345 |
3/8-24 |
0.3496 0.3175 |
2.86 3.15 |
| 2/0 | 0.331 0.312 |
3/8-16 | 0.2923 0.2597 |
3.42 3.85 |
| 1/0 | 0.306 |
0.2498 |
4.00 | |
| 1 | 0.283 0.272 |
5/16-24 5/16-18 |
0.2136 0.1974 |
4.68 5.07 |
| 2 | 0.262 0.250 |
0.1831 0.1667 |
5.46 6.00 |
|
| 3 | 0.244 0.228 |
1/4-32 |
0.1588 0.1387 |
6.30 7.21 |
| 4 | 0.225 0.212 |
1/4-28 1/4-20 |
0.1350 0.1199 |
7.40 8.34 |
| 5 | 0.207 |
0.1143 |
8.75 |
|
| 6 |
0.192 0.190 0.187 0.186 |
12-28 12-24 |
0.09834 0.09630 0.09328 0.09229 |
10.17 10.38 10.72 10.84 |
| 7 |
0.177 0.167 |
10-32 |
0.08357 0.07440 |
11.97 13.44 |
| 8 |
0.162 0.160 0.156 |
10-24 |
0.07001 0.06829 0.06492 |
14.28 14.64 15.40 |
| 9 |
0.148 0.144 0.141 |
8-36 8-32 |
0.05843 0.05532 0.05303 |
17.11 18.08 18.86 |
| 10 | 0.135 0.125 |
0.04862 0.04168 |
20.57 23.99 |
|
| 11 | 0.120 0.115 |
6-40 6-32 |
0.03841 0.03528 |
26.03 28.35 |
| 12 | 0.105 0.096 0.094 |
5-40 4-48 4-40 |
0.02941 0.02458 0.02357 |
34.00 40.68 42.43 |
| 13 |
0.092 |
4-36 | 0.02258 |
44.29 |
| 14 | 0.080 |
0.01707 |
58.57 |
|
| 15 | 0.072 | 0.01383 | 72.31 | |
| 16 | 0.062 | 0.01025 | 97.52 | |
| 17 | 0.054 | 0.007779 | 128.56 | |
| 18 | 0.048 | 0.006146 | 162.70 | |
| 19 | 0.041 | 0.004484 | 223.00 | |
| 20 | 0.035 | 0.003268 | 306.02 |
HOW TO GET BEST PRICE OF INCONEL X750 WIRE ?
If looking for Alloy X750 Wires in exact length so first check Inconel Alloy X750 Wires price per KG in India and calculate with wight chart before negotiating with your supplier.
| Grade | Ni | Cr | Al | C | Mn | Ti | Cu | Si | S |
| Inconel X-750 | 70.0 min | 14.0 – 17.0 | 0.40 – 1.0 | .08 max | 1.00 max | 2.25 – 2.75 | 0.50 max | .50 max | .01 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel X-750 | 1430°C | 1267 MPa | 868 MPa | 25 % |
We offer a broad range of ASTM B637 Inconel Alloy X-750 Wires through a worldwide network of stock-keeping branches. These Inconel X-750 Welding Wire is use in various industries like :
