Steelo Fabrica is the leading manufacturing and supplying industry of EN-353 round bars and rods. We are expertise in the field of manufacturing metal products.
Round bars and rods are generally used in the sectors like construction areas, where surface finish and precise dimensions required are, mostly considered for round bars. It works as a connector between pipes in the middle.
Table of Content
Composition of the EN – 353 Round bars:
These round bars and rods are manufactured out of the finest nickel alloys. It consisted of carbon, manganese, silicon, sulfur, phosphorus, chromium, and molybdenum near about 0.17% of carbon present in it makes it stronger.
This composition helps round bars to work smoothly as per the applications. Nickel exists in the round bar enables it to be more ductile. Iron and other elements act as hardening agents, which help to the prevention of movement dislocation.
Properties that make round rods more popular:
EN – 353 round bar is a very high-strength steel alloy that is hardened and tempered before supplying. It has a high corrosion resistivity as it is a more remarkable strength steel alloy.
Few mechanical properties such as tensile strength, yield strength, elongation, and others are also comprised in round bars. However, it is highly recommended for the construction sector because of its lower cost and higher strength property.
These rods are also used as a plug-in for resisting pressure in pressure valves.
What is the Application field of EN – 353 Round bars?
Some of the industries in which EN- 353 round bar are used are listed as below:
Round bars are extensively used in the above industry as these industries require precise dimensions and higher finish.
ASTM A-510
ASME SA-510
AFNOR 20NCD5
GERMAN DIN 20NiCrMo5
Specification : ASTM A510, ASME SA510
size: 4 to 100mm
Hollow Bar : 32mm OD x 16mm ID to 250mm OD x 200mm ID)
Hex Bar : 2-100mm A/F
Angle bar size : 3mm*20mm*20mm~12mm*100mm*100mm
Rectangles Size : 33 x 30mm to 295 x 1066mm
Flat bar size : Thickness: 2 -100mm, Width: 10 to 500mm
Channel Bar : 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness
Section : 3.0 to 12.0mm thickness
Round bar size : Diameter: 3-~800mm
Round Bar Billet Size : 1/2″ to 495mm Diameter
Round Bar Surface : Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline
EN-353 Tolerance : H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
EN-353 Technique : EN-353 Round Bar Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod
Round Bar Condition : Hardened & tempered, annealed
Finish : Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
Processing : Bar cutting to 650mm
| EUROPEAN STANDARD | GERMAN DIN | FRENCH AFNOR | SWEDISH SS | BRITISH BS | BRITISH BS |
| EN10277-4 | 20NiCrMo5 | 20NCD5 | 2523 | BS 970:1991 815M17 | BS 970:1955 EN353 |
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
| Cut to size on request (tolerance +2/-0 mm). Standard lengths of en 353 Bars 2000 mm up to 6000 mm available | |||
| 5.0 | 45.0 | ||
| 6.0 | 50.0 | ||
| 7.0 | 55.0 | ||
| 8.0 | 60.0 | ||
| 9.0 | 65.0 | ||
| 10.0 | 70.0 | ||
| 12.0 | 75.0 | ||
| 16.0 | 80.0 | ||
| 20.0 | 90.0 | ||
| 25.0 | 100.0 | ||
| 30.0 | 130.0 | ||
| 35.0 | 160.0 | ||
| 40.0 | 200.0 | ||
HOW TO GET BEST PRICE OF EN 353 Round Bars ?
If looking for EN 353 Round Rods in exact length so first check Alloy Steel EN 353 price per KG in India and calculate with wight chart before negotiating with your supplier.
| Grade | C | Ma | Si | Su | Ph | Ch | Mo | Ni |
| EN 353 | 0.10 – 0.20 | 0.50 – 1.00 | 0.10 – 0.35 | Max 0.040 | Max 0.040 | 0.75 – 1.25 | 0.08 – 0.15 | 1.00 – 1.50 |
Soft annealing °C |
Cooling |
Hardness HB |
|---|---|---|
630-670 |
Furnace |
max. 270 |
Stress-relief annealing °C |
Cooling |
|---|---|
150-200 |
Furnace |
We offer a broad range of ASTM A510 EN 353 Round Bars through a worldwide network of stock-keeping branches. These EN 353 Alloy Steel Round Bar is use in various industries like :
