Steelo Fabrica is the leading manufacturer and seller of Naval Brass UNS C48200 Forged Bars. Our C48200 Naval Brass alloy displays a great capacity for being hot worked and cold worked moderately, and it makes for the perfect alloy for salt and freshwater immersion.
Table of Content
What is Naval Brass UNS C48200?
Naval Brass is a copper alloy of around 59% Copper, 40% Zinc and 1% Tin with a trace amount of Lead. This alloy falls into the subfamily of Brasses known as Alpha Beta or Duplex Brasses. These Alpha Beta Brasses are generally harder and stronger than other non-alpha Beta Brasses. Tin is included in the alloy composition to improve the corrosion resistance of the Naval Brass. C48200 Naval brass is a brass formulated for primary forming into wrought products. CW714R is the EN numeric designation for this material, and C48200 is the UNS number. Additionally, the EN chemical designation is CuZn37Pb1Sn1.
Forging of the bars:
UNS C48200 alloys have a hot forge ability rating of 90, with the recommended hot working temperature between 649 and 760°C. Therefore the forged bars possess very good machinability as manufacturers under these dimensions.
Properties: Naval brass UNS C48200 Rods are the classic marine, high-strength, and corrosion-resistant alloy. It is widely used in marine construction where strong, corrosive-resistant and hard material is required and suitable for salt and fresh water applications. These bars and rods are fair to excellent corrosion resistance. These forged bars and rods are Good and hot workability for hot forging, pressing, and machining operations.
Applications: As its name implies, Naval Brass was originally developed for seawater service applications. Naval Brass UNS C48200 Rods are widely used in marine construction where strong, corrosive-resistant and hard material is required and is suitable for both salt and fresh water applications. Other applications are found in –
-Decorative And Architectural Products
-Marine Hardware
-screw machine products,
-valve stems.
ASTM B-21
ASME SB-21
UNS C48200
EN
CW714R
Specification : ASTM B21/ ASME SB21
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Hollow Bars : Min Bore Size 20 mm and Max OD 100 mm
Round Bars : 6mm To 130 mm
Hex Bars : 5mm To 60mm
Square Bars : 4mm To 60mm
Billets : Up to 200 mm
Ingots: AS per Specification
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Length : 1 to 6 Meters, Custom Cut Lengths
Form : Round, Square, Hex (A/F), Rectangle Etc.
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
HOW TO GET BEST PRICE OF Naval Brass C48200 Forged BAR ?
If looking for Naval Brass C48200 Forged Bars and Rod in exact length so first check Naval Brass C48200 Bars price per KG in India and calculate with wight chart before negotiating with your supplier.
| Cu | Fe | Pb | Sn | Zn | |
| Min/Max | 59.0-62.0 | 0.10 | 40-1.0 | 0.50-1.0 | Rem |
| Nominals | 61.5000 | – | .7 | 8 | 38.0 |
We offer a broad range of ASTM B21 Naval Brass C48200 Forged Bars through a worldwide network of stock-keeping branches. These C48200 Naval Brass Bars and Rods is use in various industries like :
