We, Steelo Fabrica, have the production of forged bars Alloy 254 Rod, which is done with the effectiveness so that all purchasers can be secure in buying good quality of the product. These product is designed by using the high quality of the alloy with various international and national product standard abilities.
Table of Content
Introduction Of Forged Rod UNS S31254:
The bar has a highly alloyed austenitic stainless steel grade. The stainless steel grade has been developed for use in the seawater and further aggressive chloride-containing media. Also, it has a high resistance to stress-related corrosion cracking. Some characteristics of the alloy include its excellent resistance to pitting and crevice corrosion.
The UNS S31254 is also known for 6 Mo. It has a super austenitic stainless steel with the high level of molybdenum and nitrogen element. These alloys provide high resistance to pitting and crevice corrosion. Also, it offers high strength compared with the other conventional austenitic stainless steel like 316L.
Components Of These Alloy
These alloys have mainly comprised of chromium, nickel, molybdenum element like standard austenitic stainless steel grades. The, unlike convention austenitic stainless steel grades, contains about nitrogen. The levels of the component like chromium, nickel, molybdenum and nitrogen have its super austenitic bar, which are combined by its impact toughness resistance to corrosion cracking with the pitting and crevice corrosion resistance. The Round Bar has a chemical mixture of an element such as manganese, sulfur, copper, silicon, nickel, molybdenum, phosphorous, chromium element.
Properties Of Forged Rod Alloy 254 Rod:
Alloy 254 is a Chromium-Nickel alloy that possesses excellent corrosion-resistant to chemical attacks and reducing agents. Also, these alloy has high-temperature strength that can be applied in high-temperature applications. These alloy brings out numerous good features. These features are durable, accurate dimension, corrosion resistance, abrasion resistance. It can resist high temperatures, although maintaining its high strength under volatile conditions.
Application Of Forged Bar UNS S31254:
This Alloy is used in applications like flue gas desulfurization and the chemical environments. Also, it is used in desalination equipment, seawater handling equipment, food processing equipment, heat exchangers, hydrometallurgy, pulp mill bleach systems, oil and gas production equipment.
ASTM A-276
ASME SA-276
UNS S31254
WNR. 1.4547
Specification : ASTM A276, A479 / ASME SA276, SA479
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 1000 MM TO 7000 MM
Outer Diameter : 100MM TO 400 mm Max OD
Weight : 1000 to 6000 Kg
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Tolerance : 0/+2-3mm
STANDARD | UNS | WERKSTOFF NR. | EN | AFNOR |
254 SMO | S31254 | 1.4547 | X1CrNiMoCuN20-18-7 | Z1 CNDU 20.18.06Az |
US Bar | Metric | Japanese | Canadian/ASTM | ||||
---|---|---|---|---|---|---|---|
Diameter(Inch) | SMO 254 Bar Size | Diameter (millimeter) | SMO 254 Bar Size | Diameter (millimeter) | SMO 254 Bar Size | Diameter (millimeter2) | SMO 254 Bar Size |
0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
1.250 | #10 | 12 | 12 | 32 | 32 | ||
1.375 | #11 | 14 | 14 | 35 | 35 | ||
1.500 | #12 | 16 | 16 | 38 | 38 | ||
1.625 | #13 | 18 | 18 | 41 | 41 | ||
1.750 | #14 | 20 | 20 | 44 | 44 | ||
1.875 | #15 | 22 | 22 | 48 | 48 | ||
2.000 | #16 | 25 | 25 | 51 | 51 | ||
2.250 | #18 | 28 | 28 | 57 | 57 | ||
32 | 32 | ||||||
36 | 36 | ||||||
40 | 40 | ||||||
44 | 44 | ||||||
50 | 50 |
Diameter in inch | Size in inch/MM | Weight Lbs/ft & Kg/M |
---|---|---|
1/16 | 0.0625 1.5875 | 0.010 / 0.01488 |
1/8 | 0.125 3.175 | 0.042 / 0.062496 |
3/32 | 0.0938 2.38252 | 0.0240 / 0.035712 |
5/32 | 0.1563 3.97002 | 0.065 / 0.09672 |
7/32 | 0.2188 5.55752 | 0.128 / 0.190464 |
3/16 | 0.1875 4.7625 | 0.094 / 0.139872 |
1/4 | 0.25 6.35 | 0.167 / 0.248496 |
5/16 | 0.3125 7.9375 | 0.260 / 0.38688 |
9/32 | 0.2813 7.14502 | 0.211 / 0.313968 |
3/8 | 0.375 9.525 | 0.376 / 0.559488 |
1/2 | 0.5 12.7 | 0.668 / 0.993984 |
7/16 | 0.4375 11.1125 | 0.512 / 0.761856 |
9/16 | 0.5625 14.2875 | 0.844 / 1.255872 |
11/16 | 0.6875 17.4625 | 1.264 / 1.880832 |
5/8 | 0.625 15.875 | 1.043 / 1.551984 |
3/4 | 0.75 19.05 | 1.502 / 2.234976 |
7/8 | 0.875 22.225 | 2.045 / 3.04296 |
13/16 | 0.8125 20.6375 | 1.761 / 2.620368 |
15/16 | 0.9375 23.8125 | 2.35 / 3.4968 |
1 1/16 | 1.0625 26.9875 | 3.012 / 4.481856 |
1 | 1 25.4 | 2.671 / 3.974448 |
1 1/8 | 1.125 28.575 | 3.38 / 5.02944 |
1 1/4 | 1.25 31.75 | 4.173 / 6.209424 |
1 3/16 | 1.1875 30.1625 | 3.77 / 5.60976 |
1 5/16 | 1.3125 33.3375 | 4.598 / 6.841824 |
HOW TO GET BEST PRICE OF SMO 254 FORGED BAR ?
If looking for 254 Forged Bars and Rod in exact length so first check SMO 254 price per KG in India and calculate with weight chart before negotiating with your supplier.
Grade | C | Ni | Si | N | S | Mn | P | Cr | Ce | Fe | |
SS 254 SMO | min. | – | 17.5 | – | 0.18 | – | – | – | 19.5 | 0.03 | Balance |
max. | 0.02 | 18.5 | 0.08 | 0.22 | 0.01 | 1.00 | 0.03 | 20.5 | 0.08 |
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
254 SMO | 650 | 35 | 300 | 50 | 270 |
We offer a broad range of ASTM A276 SMO 254 Forged Bars through a worldwide network of stock-keeping branches. These 254 SMO Forged Rods is use in various industries like :
