We at Steelo Fabrica produce huge stocks of multiple grades, alloys, lengths and Diameters of Brass IS 319 Grade 2 Forged Bar. We have been working for our esteemed clients of different industrial sectors like the Component manufacturing and Aerospace Sector for the Long Run. We offer a massive variety of several grades, finishes, lengths of these Rod products for our valued customers. We have been serving our clients in the Component manufacturing and Aerospace Sector for the Long Run.
Table of Content
General description of Brass IS 319 Grade 2
IS 319 Grade 2 is generally recognized as UNS C36000 or CDA360. This alloy especially stands out as a perfect choice when machinability is the prime consideration. Primarily due to the presence of 3% Lead in the material, this material tends to be the most economical material for tapping, threading, and milling or turning. It exhibits long tool life and an excellent surface finish. These bars are vastly used for making Components, Shafts, Tools, Machines and other high precision products in the Industrial Sectors.
Chemical Compositions Brass IS 319 Grade 2 Rods:-
The composition of Brass IS 319 Grade 2 Rods are mainly consisting of components like Copper in 60 to 63 %, Lead in 2.5 to 3.70 %, Iron in 0.35% Max. This alloy also contains Zinc in Balance, and Other Impurities excel Fe. In 0.5% Max amount.
What Are The Key Features of Brass IS 319 Grade 2 Forged Bars?
Our produced Brass IS 319 Grade 2 Forged Bars are excellent for soft soldering and Brazing. These bars are highly appreciated for their Good Corrosion resistance, and these products also possess excellent Cutting properties with good machinability.
Brass IS 319 Grade 2 Forged Bars holds Yield Stress of about 150 MPa Min. and also possess Tensile Strength of around 325 MPa Min.
The main applications of these high-grade Brass IS 319 Grade 2 Rod is found in the making of hinges, locks, butts, screws, nuts and bolts, etc.
Specification : ASTM B21/ ASME SB21
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Round Bars : Outside Diameter in the range of 4mm to 500mm
Bright Bars : Outside Diameter in the range of 4mm to 100mm
Hex Bars : 18mm – 57mm (11/16″ to 2-3/4″)
Square Bars : 18mm – 47mm (11/16″ to 1-3/4″)
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Length : 1 to 6 Meters, Custom Cut Lengths
Form : Round, Square, Hex (A/F), Rectangle Etc.
|BD||Bright drawn||SRE||Slit rolled edge|
|CG||Centreless ground||HF||Hot finished|
|CF||Cold finished||HRAP||Hot rolled annealed and pickled|
|P&T||Peeled and turned||RT||Rough turned/peeled|
|ST||Smooth turned||PR||Peeled and reeled|
|Chemical Requirements||Grade I|
|Cu||56 to 58 %|
|Pb||2 to 3.50 %|
|Other Impurities excel Fe.||0.75% Max|
|Yield Stress||150 MPa Min.|
|Tensile Strength||380 MPa Min.|
|Hardness Brinell||90 to 160 HB|
We offer a broad range of Brass IS 319 Grade 2 Forged Bars / Rods through a worldwide network of stock-keeping branches. These IS 319 Grade 2 Brass Alloys Forged Bars and Rods is use in various industries like :
