Steelo Fabrica is experienced in manufacturing superb eminence Stainless Steel 317 Round Bar to accomplish large industrial demand. We stock Bars with authorized standards and specifications in addition to a variety of sizes, forms, and finishes. According to customer needs, our bars are accessible in several industries. These bars are proposed for excellent performance in several corrosive conditions and temperature dealing applications.
SS 317 Round Bar is made in round size and range of dimensions using superior grade material of 317. It is an improved variation of Stainless Steel grade 316. Increased Molybdenum content in Nickel-Chromium-Iron alloy benefits boosts in strength along with pitting corrosion resisting property. The grade is strengthened with hardness and yield strength. It is weldable, cold hardened, and hot workable.
Table of Content
Sort of Stainless Steel 317 Round Bar:
Stainless Steel 317 Round Bar is a non-magnetic, superior strength bar suitable to use as cold-worked and annealed form. These Bars are produced with austenitic features and are less conductive in electrical energy. These bars are enriched with higher creep and chloride corrosion resistance, stress cracking strength, weldability, and durability.
Where to employ Stainless Steel 317 Round Bar?
Stainless Steel 317 Round Bar is mainly proposed in chemical processing as it is excellently defiant to decay in sarcastic media. When used in high-temperature applications, these bars illustrate thermal stability. The Bar is surface polished and does not easily get corroded. It is aqueous corrosion-proof introducing opposition to oxidization in saltwater as well as freshwater surroundings.
These bars are used in several applications in fertilizer plants, chemical plants, sugar mills, condensers, heat exchangers, and the automobile industry.
ASTM A-276
ASME SA-276
UNS S31700
WNR. 1.4449
Specification : ASTM A276, A479 / ASME SA276, SA479
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Round Bars : Outside Diameter in the range of 4mm to 500mm
Bright Bars : Outside Diameter in the range of 4mm to 100mm
Hex Bars : 18mm – 57mm (11/16″ to 2-3/4″)
Square Bars : 18mm – 47mm (11/16″ to 1-3/4″)
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Length : 1 to 6 Meters, Custom Cut Lengths
Form : Round, Square, Hex (A/F), Rectangle Etc.
STANDARD | UNS | WERKSTOFF NR. | EN | JIS |
SS 317 | S31700 | 1.4449 | – | SUS 317 |
CD | Cold drawn | P | Polished |
BD | Bright drawn | SRE | Slit rolled edge |
CG | Centreless ground | HF | Hot finished |
CF | Cold finished | HRAP | Hot rolled annealed and pickled |
P&T | Peeled and turned | RT | Rough turned/peeled |
ST | Smooth turned | PR | Peeled and reeled |
US Bar | Metric | Japanese | Canadian/ASTM | ||||
---|---|---|---|---|---|---|---|
Diameter(Inch) | Stainless Steel 317 Bar Size | Diameter (millimeter) | Stainless Steel 317 Bar Size | Diameter (millimeter) | Stainless Steel 317 Bar Size | Diameter (millimeter2) | Stainless Steel 317 Bar Size |
0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
1.250 | #10 | 12 | 12 | 32 | 32 | ||
1.375 | #11 | 14 | 14 | 35 | 35 | ||
1.500 | #12 | 16 | 16 | 38 | 38 | ||
1.625 | #13 | 18 | 18 | 41 | 41 | ||
1.750 | #14 | 20 | 20 | 44 | 44 | ||
1.875 | #15 | 22 | 22 | 48 | 48 | ||
2.000 | #16 | 25 | 25 | 51 | 51 | ||
2.250 | #18 | 28 | 28 | 57 | 57 | ||
32 | 32 | ||||||
36 | 36 | ||||||
40 | 40 | ||||||
44 | 44 | ||||||
50 | 50 |
Diameter in inch | Size in inch/MM | Weight Lbs/ft & Kg/M |
---|---|---|
1/16 | 0.0625 1.5875 | 0.010 / 0.01488 |
1/8 | 0.125 3.175 | 0.042 / 0.062496 |
3/32 | 0.0938 2.38252 | 0.0240 / 0.035712 |
5/32 | 0.1563 3.97002 | 0.065 / 0.09672 |
7/32 | 0.2188 5.55752 | 0.128 / 0.190464 |
3/16 | 0.1875 4.7625 | 0.094 / 0.139872 |
1/4 | 0.25 6.35 | 0.167 / 0.248496 |
5/16 | 0.3125 7.9375 | 0.260 / 0.38688 |
9/32 | 0.2813 7.14502 | 0.211 / 0.313968 |
3/8 | 0.375 9.525 | 0.376 / 0.559488 |
1/2 | 0.5 12.7 | 0.668 / 0.993984 |
7/16 | 0.4375 11.1125 | 0.512 / 0.761856 |
9/16 | 0.5625 14.2875 | 0.844 / 1.255872 |
11/16 | 0.6875 17.4625 | 1.264 / 1.880832 |
5/8 | 0.625 15.875 | 1.043 / 1.551984 |
3/4 | 0.75 19.05 | 1.502 / 2.234976 |
7/8 | 0.875 22.225 | 2.045 / 3.04296 |
13/16 | 0.8125 20.6375 | 1.761 / 2.620368 |
15/16 | 0.9375 23.8125 | 2.35 / 3.4968 |
1 1/16 | 1.0625 26.9875 | 3.012 / 4.481856 |
1 | 1 25.4 | 2.671 / 3.974448 |
1 1/8 | 1.125 28.575 | 3.38 / 5.02944 |
1 1/4 | 1.25 31.75 | 4.173 / 6.209424 |
1 3/16 | 1.1875 30.1625 | 3.77 / 5.60976 |
1 5/16 | 1.3125 33.3375 | 4.598 / 6.841824 |
HOW TO GET BEST PRICE OF SS 317 ROUND BAR ?
If looking for 317 Bars and Rod in exact length so first check ss 317 price per KG in India and calculate with wight chart before negotiating with your supplier.
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
SS 317 | 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We offer a broad range of ASTM A276 SS 317 Round Bars through a worldwide network of stock-keeping branches. These 317 Stainless Steel Round Bar is use in various industries like :
